Year/condition 2019/85% new
|
Category
|
Item
|
Unit
|
XCT12L4
|
|
Dimension
|
Overall length
|
mm
|
10900
|
|
Overall width
|
mm
|
2500
|
|
|
Overall height
|
mm
|
3550
|
|
|
Weight
|
Total weight in travel
|
kg
|
16000
|
|
Travel
|
Max. travel speed
|
km/h
|
90
|
|
Min. turning diameter
|
m
|
18
|
|
|
Min. ground clearance
|
mm
|
250
|
|
|
Approach angle
|
°
|
21
|
|
|
Departure angle
|
°
|
13
|
|
|
Max. grade ability
|
%
|
41
|
|
|
Fuel consumption for 100km
|
L
|
25
|
|
|
Main performance
|
Max. rated total lifting capacity
|
t
|
12
|
|
Min. rated working radius
|
m
|
3
|
|
|
Turning radius at turntable tail
|
m
|
2.57
|
|
|
Max. lifting torque
|
kN.m
|
482.5
|
|
|
Base boom
|
m
|
9.5
|
|
|
Max.main boom
|
m
|
30.9
|
|
|
Max.main boom+jib
|
m
|
38.1
|
|
|
Max. load moment
|
Base boom
|
t.m
|
48.25
|
|
Fully-extended boom
|
t.m
|
27.6
|
|
|
Hoist height
|
Lateral
|
m
|
5.5
|
|
Base boom
|
m
|
9.5
|
|
|
Fully-extended boom
|
m
|
30.9
|
|
|
Boom length
|
Fully-extended boom + Jib
|
m
|
38.1
|
|
Base boom
|
m
|
9.45
|
|
|
Fully-extended boom
|
m
|
30.5
|
|
|
Fully-extended boom + Jib
|
m
|
30.5+7
|
